Pulse Compression Gratings

Pulse compression gratings are used to compress or stretch laser pulses and are commonly used in Chirped Pulse Amplification (CPA) laser systems.

Spectrum Scientific’s pulse compression gratings offer high efficiency coupled with excellent surface quality and high damage threshold.

Typical substrates include Zerodur®, Pyrex and fused silica to maximize thermal stability and all of our pulse compression gratings are supplied with a high reflectivity gold coating.

Spectrum Scientific offers a range of standard gratings, however, if we do not have a grating that meets your requirement we can manufacture bespoke gratings.

For volume pricing or custom designs, please complete our Request Information form or contact our sales team to discuss your specific requirements.

Pulse Compression Gratings
Pulse Compression Gratings
Advanced Filter

Product Groove Density (g/mm)

Product Wavelength of Peak Efficiency (nm)

Product Wavelength Range (nm)

Product Coating

Product Dimensions (mm)

Product Lead Time

Product Apex Distance (inches)

Product Beam Deviation (arcsec)

Product Blaze Wavelength (nm)

Product Clear Aperture (mm)

Product Clear Aperture (%)

Product Deflection Angle (deg)

Product Deviation Angle (deg)

Product Dia. (mm)

Product Dispersion (nm/mm)

Product Effective Fl (mm)

Product F Nbr

Product Lα (mm)

Product Lβ (mm)

Product Parent Fl (mm)

Product Peak Efficiency (%)

Product Size (mm)

Product Spectrum Length (mm)

Product Substrate

Product Surface Accuracy

ComparePart NumberProduct DescriptionPriceGroove Density (g/mm)Blaze Wavelength (nm)QuantityMore
Compare 1200-1550-30/90 1200 g/mm, 1550nm Holographic Grating (S-Pol), 30 x 90mm $ 1200 1550 (S Pol)
Part Number: 1200-1550-30/90
Price: $
Groove Density (g/mm)1200
Blaze Wavelength (nm)1550 (S Pol)
Peak Efficiency (%)94% (S Pol)
Wavelength Range (nm)1550 - 1650 (S Pol)
CoatingGold
Size (mm)30 x 90
Lead Time2-4 Wks
Hide Details
Compare 1480-1100-30/90 1480 g/mm, 1100nm Holographic Grating (S-Pol), 30 x 90mm $ 1480 1100 (S Pol)
Part Number: 1480-1100-30/90
Price: $
Groove Density (g/mm)1480
Blaze Wavelength (nm)1100 (S Pol)
Peak Efficiency (%)94% (S Pol)
Wavelength Range (nm)900 - 1200 (S Pol)
CoatingGold
Size (mm)30 x 90
Lead Time2-4 Wks
Hide Details
Compare 1740-1053-30/90 1740 g/mm, 1053nm Holographic Grating (S-Pol), 30 x 90mm $ 1740 1053 (S Pol)
Part Number: 1740-1053-30/90
Price: $
Groove Density (g/mm)1740
Blaze Wavelength (nm)1053 (S Pol)
Peak Efficiency (%)93% (S Pol)
Wavelength Range (nm)1000 - 1088 (S Pol)
CoatingGold
Size (mm)30 x 90
Lead Time2-4 Wks
Hide Details
Compare 2322-300-30/90 2322 g/mm, 300nm Holographic Grating (P-Pol), 30 x 90mm $ 2322 300 (S Pol)
Part Number: 2322-300-30/90
Price: $
Groove Density (g/mm)2322
Blaze Wavelength (nm)300 (S Pol)
Peak Efficiency (%)85% (S Pol)
Wavelength Range (nm)280 - 3325 (P Pol)
CoatingAluminum
Size (mm)30 x 90
Lead Time2-4 Wks
Hide Details
Compare 700-1100-30/90 700 g/mm, 1100nm Holographic Grating (S-Pol), 30 x 90mm $ 700 1150 (S Pol)
Part Number: 700-1100-30/90
Price: $
Groove Density (g/mm)700
Blaze Wavelength (nm)1150 (S Pol)
Peak Efficiency (%)75% (S Pol)
Wavelength Range (nm)950 - 2800 (S Pol)
CoatingGold
Size (mm)30 x 90
Lead Time2-4 Wks
Hide Details

Please complete our Request Information form or contact our sales team to discuss your specific requirements.
